WireGuard VPN on a Raspberry Pi: replace OpenVPN in 15 minutes

WireGuard VPN Raspberry Pi setup — official WireGuard logo

Setting up a WireGuard VPN on a Raspberry Pi is one of the best home networking projects you can do — WireGuard is faster, simpler, and more auditable than OpenVPN, and it runs natively in the Linux kernel. This guide walks through the complete WireGuard VPN Raspberry Pi configuration: server setup, key generation, client config for iOS, Android, and macOS, and integration with Pi-hole for network-wide ad blocking over VPN. All commands in this WireGuard VPN Raspberry Pi guide were tested on Raspberry Pi OS Lite 64-bit.

What you need

  • A Raspberry Pi (3B+, 4B, or 5 recommended)
  • Raspberry Pi OS Lite (64-bit preferred)
  • A static IP or DDNS hostname pointing to your home network
  • Port forwarding: UDP 51820 open on your router, forwarded to the Pi’s local IP

Install WireGuard

WireGuard is in the standard Raspberry Pi OS repos (Bullseye or later):

sudo apt update && sudo apt install -y wireguard

Generate server keys

wg genkey | tee /etc/wireguard/server_private.key | wg pubkey > /etc/wireguard/server_public.key
chmod 600 /etc/wireguard/server_private.key

Note the values — you’ll need them in the config:

cat /etc/wireguard/server_private.key
cat /etc/wireguard/server_public.key

WireGuard VPN Raspberry Pi server configuration

Find your network interface name first:

ip -o -4 route show to default | awk '{print $5}'
# Typically: eth0 or wlan0

Create /etc/wireguard/wg0.conf:

[Interface]
Address = 10.8.0.1/24
ListenPort = 51820
PrivateKey = YOUR_SERVER_PRIVATE_KEY

PostUp = iptables -A FORWARD -i wg0 -j ACCEPT; iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
PostDown = iptables -D FORWARD -i wg0 -j ACCEPT; iptables -t nat -D POSTROUTING -o eth0 -j MASQUERADE

Enable IP forwarding

echo "net.ipv4.ip_forward=1" | sudo tee -a /etc/sysctl.conf
sudo sysctl -p

Add a client peer

wg genkey | tee /etc/wireguard/client1_private.key | wg pubkey > /etc/wireguard/client1_public.key

Add to wg0.conf:

[Peer]
PublicKey = CLIENT1_PUBLIC_KEY
AllowedIPs = 10.8.0.2/32

Client config file:

[Interface]
PrivateKey = CLIENT1_PRIVATE_KEY
Address = 10.8.0.2/24
DNS = 10.8.0.1

[Peer]
PublicKey = SERVER_PUBLIC_KEY
Endpoint = your-ddns-or-public-ip:51820
AllowedIPs = 0.0.0.0/0
PersistentKeepalive = 25

Start the WireGuard server

sudo systemctl enable --now wg-quick@wg0
sudo wg show

Import the client config

iOS / Android: Generate a QR code:

sudo apt install -y qrencode
qrencode -t ansiutf8 < /etc/wireguard/client1.conf

macOS: Install the WireGuard app from the App Store and import the .conf file.

Combine WireGuard with Pi-hole

If you're running Pi-hole on the same device, set DNS = 10.8.0.1 in the client config and choose wg0 as Pi-hole's listening interface. (The Pi-hole guide on this site was written for OpenVPN, so use it for the Pi-hole installation only and replace tun0 with wg0.) All DNS queries from your phone will go through Pi-hole when the VPN is active — ad blocking works on any network, not just at home.

Troubleshooting

  • Handshake not completing — check port forwarding and that UDP 51820 is open on the server firewall
  • Connected but no internet — check IP forwarding is enabled and the iptables MASQUERADE rule is applied
  • DNS not resolving — ensure Pi-hole listens on the wg0 interface
  • Traffic drops — add PersistentKeepalive = 25 to keep the connection alive through NAT
